China factory Input 540-1000 Rpm Tmr Mixer or Biogas Plant Mixer Gearbox planetary gearbox efficiency

Product Description

Gearboxes for TMR Mixer or Biogas Plant Mixer



• It’s a group of factories providing one-stop solution of agricultural
• Gearbox: planetary gearbox, worm gearbox, helical gearbox…
• Chain drives: chain and Sprocket
• Coupling: rigid coupling, flexible coupling
• Components for the OEM.
• Another:PTO shaft,hydraulic motor,cylinder,valve box

Output toruqe

30000N.m (max)

Gear Ratio

1:13.4 / 1:24.18

Input speed

1000RPM (Max)

Input shaft

Single / Double input spline shaft

Weight

250KG
